Refrigerator Motor Fan 25W 35W 40W 60W 75W 90W 220V-240V AC Asynchronous Shaded Pole Freezer Fridge Cooling Fan Refrigerator
SPECIFICATIONS
Refrigerator Motor Fan 25W 35W 40W 60W 75W 90W 220V-240V AC Asynchronous Shaded Pole Freezer Fridge Cooling Fan Refrigerator
Brand Name: HYSMOTOR
Certification: CCC
Certification: ce
Certification: ROHS
Efficiency: IE 1
AC Voltage: 208-230 / 240 V
Origin: Mainland China
Protect Feature: Explosion-proof
Certification: CCC
Output Power: 25W 35W 40W 60W 75W 90W
Type: Asynchronous Motor
Advantage
Reasonable structure design, flexible lead-out direction, shaded pole motor junction box itself can be installed in rotation
Superior shaded pole motor performance, low noise, low vibration, high-performance protection level
Using high-quality low-noise bearings, stable and reliable operation, long service life and other characteristics
Optimized design, high efficiency, can produce considerable energy-saving effect
Since different motors are adapted to different fans, we will give you the corresponding fan according to the motor you purchased
This product is an upgraded version of Pure copper wire, with better quality and longer life
model |
Direction |
diameter |
Height of black area |
enter |
Output |
Rotating speed |
Current |
Fittingfan blade diameter(mm) |
25W |
CCW |
82mm |
12mm |
25W |
2.5W |
1300RPM |
0.2A |
Plastic 170 |
40W |
CCW |
82mm |
19mm |
40W |
8W |
1300RPM |
0.3A |
Plastic 170 |
60W |
CCW |
82mm |
25mm |
60W |
12W |
1300RPM |
0.4A |
Aluminum 250 |
75W |
CCW |
82mm |
30mm |
75W |
18W |
1300RPM |
0.4A |
Aluminum 300 |
90W |
CCW |
82mm |
38mm |
90W |
25W |
1300RPM |
0.8A |
Aluminum 300 |
