Micro 390 DC Motor 6V 12V 24V High Speed 4200rpm 9426rpm 18900rpm Motors Reversed Strong Magnetic Electric DIY Model Fan RP390

SPECIFICATIONS

Micro 390 DC Motor 6V 12V 24V High Speed 4200rpm 9426rpm 18900rpm Motors Reversed Strong Magnetic Electric DIY Model Fan RP390

Brand Name: HYSMOTOR

HYSMOTOR Model: RS390

Certification: CCC

Certification: ROHS

Origin: Mainland China

Commutation: Brush

Type: Micro Motor

Protect Feature: Drip-proof

Construction: Permanent Magnet

Model Number: 390 High Speed Motor

Output shaft: 2.3 MM

Shaft length: 11.6 MM (9MM without steps)

Screw hole: 2.5 MM

Hole distance: 16 MM

Height: 47 MM (excluding front and rear bearing sleeves)

Motor outer diameter: 27.5 MM

Voltage:DC 6 V Speed: 4200 RPM

Voltage: DC 12 V Speed: 9426 RPM

Voltage: DC 24 V Speed: 18900 RPM

The rated voltage is DC12V, the sound is soft, but powerful. Suitable for vacuum cleaners, electric drills, micro-engraving machines, DIY enthusiast welfare motors, 6V-12V is also suitable for use in reducers. The motor can use the highest voltage 24V, the sound is very smooth, and the torque is greater
