400W Air cooled spindle motor 0.4KW dc motor CNC engraving machine DC12V-48V

$47.13 USD
$61.70 USD $47.13 USD
Sale Sold out
Shipping calculated at checkout.

SPECIFICATIONS

400W Air cooled spindle motor 0.4KW dc motor CNC engraving machine DC12V-48V

Operating Speed: 3000-12000r / min (12v-3000rpm, 24v-6000rpm, 36v-9000rpm, 48v-12000rpm

Model Number: 400W

Maximum Torque: 500MN. M

Drive: MOTOR

Certification: CE

Application: Milling

Product parameters
Spindle motor: Electrophoresis black DC brush motor
Working voltage: 12-48vdc
Power: 400W
Starting current: 8A
Locked rotor current: 30A
Speed: 3000-12000r / min (12v-3000rpm, 24v-6000rpm, 36v-9000rpm, 48v-12000rpm)
Torque: 500MN. M
Insulation resistance: > 2 megohm
Dielectric strength of insulation: 400V
Diameter: 52mm
Motor body length: 100mm
