2Pole MCCB TRMF2-125 240V/35kA 2P 15-125A Adjustable Mould Case Circuit Breaker

Specification

2Pole MCCB TRMF2-125 240V/35kA 2P 15-125A Mould Case Circuit Breaker

please send us an email to: info@electric-b2c.com for bulk purchasing

About this item

• Distribute Electric Energy - Mainly used to distribute electric energy and protect circuits and power equipment from overload, short circuits, under voltage and other faults
• Adjustable current : Ir (0.8-1)In
• Good Flame Retardancy - The thermosetting material has good flame retardancy, will only gradually carbonize even if encounters an open flame, and will not burn, so that is safe
• Suitable For Extreme Environments - Rated current for 100A, frequency is 50/60Hz. Environmental operating temperature from 20℃60℃, suitable for more extreme environments
• Short Circuit And Overload Protection - Possess the characteristics of small size, short circuit protection, overload protection, flame retardant shell, high segmentation, short arcing, etc.
• Protection Of Motor - Can also be used for infrequent starting and overload, short circuits and under voltage protection of the motor

Product Description

Item Type: Moulded Case Circuit Breaker
Model: TRMF2-125
Material: Thermoplastic PA6+ contact copper
Frame Current(AF): 125A
Frequency: 50/60Hz
Rated Insulation Voltage (Ui): AC 230V
Rated Voltage (Ue): AC 230V
Rated Impulse Withstand Voltage (Uimp): 8KV

Rated short-circuit Breaking Capacity, Icu: 35kA
Ics=75%Icu

Product Dimension(L*W*H): 130*50*60mm

Cat A
100a mccb,2pole mccb,125a mccb,mccb 60 amp,mccb 2p
Package List:

2 x Terminal Cover
1 x Circuit Breaker
2 x Partition Board
1 x Screw Pack
