2P Din Rail Solar PV DC Fuse Holders suitable for 10*38mm DC PV Fuse Link for Solar Photovoltaic System Protection Protector

SPECIFICATIONS

2P Din Rail Solar PV DC Fuse Holders suitable for 10*38mm DC PV Fuse Link for Solar Photovoltaic System Protection Protector automotive fuses

Usage: Low Voltage

Safety Standards: IEC

Rated voltage: DC 1000V

Model Number: EAPV-32

Certification: CE

Fuse Holder for PV String Fuses

This holder is suitable for PV fuses rated 6A, 10A, 15A, 20A, 25A, 30A and 32A. The maximum voltage is 1000V. The fuse holder can be combined with the following PV String Fuses which is essential protection for solar panels.

- 1000V DC-20B

- Modular 45mm cut out - 1 module (17,5mm) X pole

- Mounting 35mm DIN rail

- High temperature resistant plastics

- Elevated insulation characteristics

Please noted, this link only for fuse holder, if you need the fuse, please buy from the link below.
