37mm 6V 12V 24V DC Moter 7RPM to 960RPM High Torque Metal Gear Box Electric Motor New Gearmotor PWM Speed Controller
Couldn't load pickup availability
SPECIFICATIONS
37mm 6V 12V 24V DC Moter 7RPM to 960RPM High Torque Metal Gear Box Electric Motor New Gearmotor PWM Speed Controller
Brand Name: HYSMOTOR
Certification: CCC
Certification: ROHS
Origin: Mainland China
Continuous Current(A): 300ma
Output Power: 1W
Commutation: Brush
Type: Gear Motor
Protect Feature: Drip-proof
Construction: Permanent Magnet
Usage: BoAt
Usage: car
Usage: Electric Bicycle
Usage: Fan
Usage: Home Appliance
Efficiency: IE 1
Model Number: jgb37-520
Torque: 16kg.cm
DC12V 24V Large Torque Speed Reduction Gear Motor with Metal Gearbox 37GB520
Specification:
Notice: The lower speed is the larger torque
-
Voltage: DC12V
No-load Speed: 7rpm, 12rpm, 22rpm, 35rpm, 45rpm, 66rpm, 107rpm, 200rpm, 320rpm, 600rpm, 960rpm
-
Voltage: DC24V
No-load Speed: 7rpm, 12rpm, 22rpm, 35rpm, 45rpm, 66rpm, 107rpm, 200rpm, 320rpm, 600rpm, 960rpm
-
Max Power: 10W
-
Max Torque: 25kg/cm
-
Motor Diameter: 33mm
-
Motor Body Length: 22.7mm
-
Output Shaft Diameter: 6mm
-
Output Shaft Length: 15mm
-
Gearbox Diameter:37mm
-
Gearbox Length:see the table
Size¶meter:
Gear Dc Motor Show:
